Brief Introduction

KPE-16

Mounting positionAny Clamping type with active directionBoth sides Clamped by spring, released by compressed air Structural designHinge-down panes VariantsPiston rod at one end Operating pressure≤1 MPa Operating pressure≤10 bar Release pressure≥0.3 MPa Release pressure≥3 bar Round material to be clamped16 mm Operating mediumCompressed air as per ISO 8573-1:2010 [7:4:4] Information on operating and pilot mediaOperation with oil lubrication possible (required for further use) Corrosion resistance class (CRC)2 - Moderate corrosion stress LABS (PWIS) conformityVDMA24364-B1/B2-L Ambient temperature-10 °C ... 80 °C Static holding force1000 N Product weight410 g Seals materialNBR TPE-U(PU) Material of springSpring steel Housing materialAluminum Anodized Clamping jaws materialBrass Material of pistonPOM
