NPQE-D-R18-Q12-P10

SizeStandard Nominal size5 mm Type of seal on screwed plugCoating Mounting positionoptional DesignStraight design Size of pack10 DesignPush-pull principle Operating pressure complete temperature range-0.095 MPa ... 0.8 MPa Operating pressure complete temperature range-0.95 bar ... 8 bar Operating pressure complete temperature range-13.775 psi ... 116 psi Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot mediumLubricated operation possible Corrosion resistance class CRC1 - Low corrosion stress LABS (PWIS) conformityVDMA24364 zone III Cleanroom classClass 4 according to ISO 14644-1 Ambient temperature-5 °C ... 60 °C Product weight27.95 g Type of mountingExternal hexagon, size 21 mm Internal hexagon, size 5 mm Pneumatic connection, port 1Male thread R1/8 Pneumatic connection, port 2For tubing outer diameter of 12 mm Colour of release ringBlue Note on materialsRoHS-compliant Material housingBrass, nickel-plated Material thread sealPTFE Material release ringPOM Material tubing sealNBR Material tubing clamp componentStainless steel
